70dB Shielding Fabric Aaronia Shield ULTRA (50m²)

High performance shielding fabric Aaronia Shield ULTRA.
Comparable to the conventional Aaronia Shield, but with a higher damping factor of up to 70 dB and non-oxidizing.

Perfect for shielding of window surfaces indoors and even outdoors.

Can be used ideal for construction of EMC test chambers or bug-proof conference rooms due to the extremely high damping factor. We recommend the use in combination with the shielding fleece Aaronia X-Dream.

  • High damping factor: 65 dB at 1 MHz, 70 dB at 1 GHz, 46 dB at 10 GHz
  • Tested according to ASTM D 4935-10
  • Non-oxidizing construction with outer nickel layer for enhanced corrosion resistance
  • Surface resistivity: < 0.1 Ω/sq
  • Half-transparent design
  • Rustproof
  • Frostproof
  • Tearproof
  • Foldable and flexible
  • Excellent surface conductivity
  • Easy to handle and install, suitable for both professionals and beginners

Thickness: 0.085 mm
Mesh count: 200/inch
Color: Grey
Weight: Approximately 34 g/m²
Material: High-performance copper/nickel/polyester composite material

70dB Shielding Fabric-cover
