Shock or bump test mainly simulate the impact effects of product and its components encountered in usage and transit process. Through standard and high-reproducibility instant energy exchange, you can analyze the product ability to tolerate the strong external stress and the degradation of structural weaknesses to quickly obtain the data of structure strength, anti-shock appearance and anti-drop. Shock tester is one of destructive experiments, and do destructive test on the product to evaluate the product reliability and monitor the consistency of production line.
Max. Load: 30kg
Shock Height: 25~450mm
Bump Height: 25~120mm
Continuous: 999,999
Max Shock Rate: 20 pulse/min
Max Bump Rate: 120 pulse/min
Pulse Duration: 2~30mS
Peak Acceleration: 5–200g
Shock Wave: Half sine
Table Size: 450×600 / 600×600 mm
Weight: 1400kg
Size (L×W×H): 962 × 785 × 1610 mm
Power System: 100–240V / 1Φ / 2A
Air: 6 kg/cm²
Measure System (choose): KD-1200-SM1, TP3, Rt Pro
Standard: IEC68-2-27, IEC68-2-29, GB2423.5, JB/T9391-1999, GJB-150, GJB-360, JJG-498-87
